800 Twin EFI Engine: Industry-leading big bore 800 Twin EFI engine has the fastest acceleration of any Side x Side
On-Demand True AWD: Senses when the rear wheels slip to engage both front wheels with full torque, maximizing traction with true 4-wheel drive
Lowest Center of gravity: With the engine positioned behind the seat, the center-of-gravity is lowest in class for razor sharp handling and performance
Speed & Fastes Acceleration: Blazing 55 mph (88.5 km/h) top speed makes all other Side x Sides in its class eat dust
Independent Rear Suspension: Rolled independent rear suspension with an anti-sway bar and 9.5 in. (24.1 cm) or travel for a smooth ride
Ground Clearance: 10 in. (25.4 cm) of ground clearance keeps you off boulders and other trail obstacles
Adjustable seats & More: Adjustable seats, tilt steering and an adjustable passenger grab bar and a new heel pocket to lock in comfort
Lock & Ride cargo System: Exclusive cargo system lets you add or change accessories in less than a minute with no tools
50-inch Width: A 50-inch Width makes it the only trail-capable SXS on the market
All the Utility You Need: With 300 lbs. box capacity, underseat storage, and Exclusive Lock & Ride® Accessories, RANGER RZR works hard
Engine
Displacement: 760 cc
Cooling Type: Liquid
Engine Type: Twin Cylinder
Top Speed: 55 mph (88.5 km/h)
Lubrication: Wet Sump
Oil Capacity: 2 qt. (1.9 l)
Carburetion: Electronic Fuel Injection
Fuel Capacity: 7.25 gal. (27.4 l)
Coolant Capacity: 4.8 qt. (4.5 l)
Alternator: 500 Watts
Drivetrain
Transmission: Automatic PVT
Gear Range: In-Line P-R-N-L-R
Drive System: 4 Wheel Shaft Drive
Suspension
Front Details: Double A-Arm with Antisway Bar
Rear Details: Rolled Independent with Antisway Bar
Front Suspension: 9.0 in. (22.9 cm) Double A-Arm with Anti-sway Bar
Rear Suspension: 9.5 in. (24 cm) Rolled Independent w/Anti-sway Bar
Front Tires: 25X8-12
Rear Tires: 25X10-12
Dimensions
Wheelbase: 77 in. (196 cm)
Turning Radius: 101.5 in. (258 cm)
Dry Weight: 945 lbs. (429 kg)
Ground Clearance: 10 in. (25 cm)
Length: 102 in. (259 cm)
Width: 50 in. (127 cm)
Height: 69 in. (75 cm)
Brakes: 4 Wheel Hydraulic Disk
Load Capacity
Box Dimension: 42 X 22 in. (107 X 56 cm)
Box Capacity: 300 lbs. (136 kg)
Payload Capacity: 740 lbs. (336 kg)
Hitch Towing Capacity: 1500 lbs. (681 kg)
Cargo System: Lock and Ride
Seating: 2
Skid Plate: Full
